  • Schneider A9F54310 iC60H MCB TP C 10A

Schneider A9F54310 iC60H MCB TP C 10A

(A9F54310)

The Schneider A9F54310 is a Type C Miniature Circuit Breaker (MCB) with three poles with a capacity of 10A and 10 KA. It protects circuits from short-circuit and overload currents. It also shields people from indirect interaction with TN and IT neutral systems. The Acti 9 range is a new style replacement for the Schneider C60HC multi-9 range, and it is compatible with both new and older type distribution boards.

  • £64.55

Description
Product Circuit Breaker
Type MCB
Dimensions
Depth 78.5 mm
Height 85 mm
Width 54 mm
Features
Ingress Protection IP20
Mounting DIN Rail
Pole Configuration TP
Short Circuit Rating 15 kA
General
Standards IEC/EN 60947-2 IEC/EN 60898-1
Unit Weight 0.375 kg
Technical Data
Current Rating 10 A
Voltage 440 V
